8" 40 WT FULL RANGE
Keyfeatures
- Program Power: 80 W
- Voice Coil Diameter: 25.40 mm
- Response: 90-19K Hz
- Sensitivity 1W/1M: 93 dB
Available Options:
Specification
Nominal Diameter
217 mm
Nominal Impedence
8.0 Ω
Nominal Power Handling(AES)
40 W
Program Power
80 W
Sensitivity (1W/1m)
93 dB
Frequency Range
90-19K Hz
Magnet Material
Ferrite
Voice Coil Diameter
25.40 mm
Winding Material
COPPER
Former Material
NOMEX
Winding Type
Outside
T/S Parameters
Resonant Frequency (FS)
90 Hz
DC Resistance (Re)
7.1 Ω
Electrical Q (Qes)
1.41
Mechanical Q (Qms)
8.25
Total Q (Qts)
1.20
Compliance Equivalent Volume (vas)
26 Ltrs
Peak Diaphragm Displacement Volume (Vd)
0.03 Ltrs
Effective Surface Area of Cone (Sd)
227 cm^2
Reference Efficiency (ƞo)
1.32%
Moving Mass including air load (Mms)
8.54 gms
Motor Strength (Bl)
4.95 T-m
Voice Coil Inductance @ 1 KHz (Le)
0.29 mH
Efficiency Bandwith Product (EBP)
64 Hz
Voice Coil Overhang (Xmax)
±1.51 mm
Mounting Info
Overall Diameter
217 mm
Baffle Cutout Diameter
192 mm
Depth
85 mm
Flange and Gasket Thickness
9 mm
Recone Kit
Recone Kit Number
REC8INCH40FR
