8" Subwoofer 600 WT PMPO
Keyfeatures
- Program Power: 300 W
- Voice Coil Diameter: 35 mm
- Response: 34-1.5K Hz
- Sensitivity 1W/1M: 88 dB
Available Options:
Category
Specification
Nominal Diameter
210 mm
Nominal Impedence
4.0 Ω
Nominal Power Handling(AES)
150 W
Program Power
300 W
Sensitivity (1W/1m)
88 dB
Frequency Range
34-1.5 KHz
Magnet Material
Ferrite
Voice Coil Diameter
35 mm
Winding Material
COPPER
Former Material
KAPTON
Winding Type
Outside
T/S Parameters
Resonant Frequency (FS)
44 Hz
DC Resistance (Re)
3.9 Ω
Electrical Q (Qes)
0.44
Mechanical Q (Qms)
11.14
Total Q (Qts)
0.43
Compliance Equivalent Volume (vas)
19.17 Ltrs
Peak Diaphragm Displacement Volume (Vd)
0.19 Ltrs
Effective Surface Area of Cone (Sd)
227 cm^2
Reference Efficiency (ƞo)
0.36%
Moving Mass including air load (Mms)
49.39 gms
Motor Strength (Bl)
11.04 T-m
Voice Coil Inductance @ 1 KHz (Le)
1.34 mH
Efficiency Bandwith Product (EBP)
100 Hz
Voice Coil Overhang (Xmax)
±8.4 mm
Mounting Info
Overall Diameter
210 mm
Baffle Cutout Diameter
180 mm
Depth
96 mm
Flange and Gasket Thickness
12 mm
Gross Weight
2.63 Kgs
Recone Kit
Recone Kit Number
REC8INCHSUB600
