10" SUBWOOFER 800WT PMPO
Keyfeatures
- Program Power: 400 W
- Voice Coil Diameter: 49.3 mm
- Response: 27-1.2K Hz
- Sensitivity 1W/1M: 89 dB
MRP ₹5060.00 /- (1 piece )
Offer Price ₹4400.00 /- (1 piece )
Category
Specification
Nominal Diameter
255 mm
Nominal Impedence
8.0 Ω
Nominal Power Handling(AES)
200 W
Program Power
400 W
Sensitivity (1W/1m)
89 dB
Frequency Range
27-1.2K Hz
Magnet Material
Ferrite
Voice Coil Diameter
49.3 mm
Winding Material
COPPER
Former Material
TIL
Winding Type
Outside
T/S Parameters
Resonant Frequency (FS)
30 Hz
DC Resistance (Re)
7.55 Ω
Electrical Q (Qes)
0.24
Mechanical Q (Qms)
5.56
Total Q (Qts)
0.23
Compliance Equivalent Volume (vas)
47.23 Ltrs
Peak Diaphragm Displacement Volume (Vd)
0.39 Ltrs
Effective Surface Area of Cone (Sd)
346.36 cm^2
Reference Efficiency (ƞo)
0.52%
Moving Mass including air load (Mms)
100 gms
Motor Strength (Bl)
24.45 T-m
Voice Coil Inductance @ 1 KHz (Le)
2.75 mH
Efficiency Bandwith Product (EBP)
125 Hz
Voice Coil Overhang (Xmax)
±11.4 mm
Voice Coil Overhang (Xmax)
±11.4 mm
Mounting Info
Overall Diameter
255 mm
Baffle Cutout Diameter
227 mm
Depth
130 mm
Flange and Gasket Thickness
14 mm
Gross Weight
5.60 Kgs
Recone Kit
Recone Kit Number
REC10INCHSUB800
